Integrated GPU, memory and MOSFET heat sink design for better overall component temperature
4+1 phase power
Custom dual white cooler
Custom white back plate
Black PCB
NVIDIA® Dynamic Super Resolution (DSR)
NVIDIA® Global Illumination (VXGI)
NVIDIA® GameWorks Technology
NVIDIA® GameStream Technology
NVIDIA® TXAA Technology
NVIDIA GPU Boost 2.0
NVIDIA PhysX® Technology
NVIDIA FXAA Technology
NVIDIA Adaptive Vertical Sync
NVIDIA Surround
Microsoft DirectX 12
NVIDIA® 3D Vision® Ready
NVIDIA SLI® Ready Technology
NVIDIA CUDA® technology
PCI Express 3.0 support
OpenGL 4.4 support
OpenCL support
NVIDIA SHIELD Ready
NVIDIA G-Sync Ready
All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.
GPU Engine Specs:
CUDA Cores 768
Base Clock (MHz) 1203
Boost Clock (MHz) 1405
Memory Specs:
Memory Speed 3365 (6730 ) MHz
Standard Memory Config 2048MB
Memory Interface Width 128-bit GDDR5
Memory Bandwidth (GB/sec) 107.68
Feature Support:
OpenGL 4.4
Bus Support PCI-E 3.0
Certified for Windows 8 Yes
Supported Technologies DirectX 12
SLI Options 2-WAY
Display Support:
Multi Monitor
Maximum Digital Resolution 4096x2160
Maximum VGA Resolution 2560x1600
HDCP Yes
HDMI Yes
Standard Display Connectors Dual Link DVI, HDMI, x3 DisplayPort 1.2
Audio Input for HDMI Internal
Power Specs:
Maximum Graphics Card Power (W) 90W
Minimum System Power Requirement (W) 350W
Supplementary Power Connectors 6-pin
Model:
Product Code 95NPH8DVE8EW
EAN Code 4895147120010
Dimensions:
Dimensions(with Bracket): 254*124.3*41.5mm
Dimensions(without Bracket): 239*111.2*38.6mm
PCI Express-compliant motherboard with one dual-width x 16 graphics slot
6-pin PCI Express supplementary power connectors
Minimum 350W or greater system power supply (with a minimum 12V current rating of 16A)
300MB of available hard-disk space
2GB system memory (4GB or higher recommended)
Microsoft Windows 10, Windows 8 & 8.1, Windows 7, Windows Vista (32 or 64-bit)
