- Factory overclocked to 1291 MHz
- 10 layer manufacturing process in HOF signature pure white color
- Totally redesigned bracket with drastically improved airflow and heat exhaust
- Extended PCB width for optimized layout and cleaner signal
- 2x 80mm fan + 1x 90mm fan
- 4x 8mm heat pipes + 3x 6mm heat pipes (total 7 nickel-plated heat pipes)
- Copper base
- Integrated MOSFET heatsink
- Customizable top HOF LED (control blinking frequency, brightness with GFE)
- Polycarbonate cover with premium die-cast aluminum accents
- Next generation IR3595 Digital PWM controller provides 2X switching frequency vs. previous generation
- 8 phase GPU + 2 phase memory power
- IR3555 with next gen DrMOS and 60A output
- Aerospace-grade GALAX Extreme Power Inductors provide ultra-long life, high endurance and low noise vs. normal power inductors
- NVIDIA® GeForce® GTX® VR Ready
- NVIDIA® Dynamic Super Resolution (DSR)
- NVIDIA® Global Illumination (VXGI)
- NVIDIA® GameWorks Technology
- NVIDIA® GameStream Technology
- NVIDIA® TXAA Technology
- NVIDIA GPU Boost 2.0
- NVIDIA PhysX® Technology
- NVIDIA FXAA Technology
- NVIDIA Adaptive Vertical Sync
- NVIDIA Surround
- Microsoft DirectX 12
- NVIDIA® 3D Vision® Ready
- NVIDIA SLI® Ready Technology
- NVIDIA CUDA® technology
- PCI Express 3.0 support
- OpenGL 4.4 support
- OpenCL support
- NVIDIA SHIELD Ready
- NVIDIA G-Sync Ready
- 所有圖片、規格及內容只供參考，並隨時作出變更而不另行通知。實際產品在不同國家會有所不同，請向所在地的經銷商或進口商進行確認。
- GPU Engine Specs:
- CUDA Cores 2816
- Base Clock (MHz) 1190
- Boost Clock (MHz) 1291
- Memory Specs:
- Memory Speed 3505 (7010 ) MHz
- Standard Memory Config 6144MB
- Memory Interface Width 384-bit GDDR5
- Memory Bandwidth (GB/sec) 336.5
- Feature Support:
- OpenGL 4.4
- Bus Support PCI-E 3.0
- Certified for Windows 8 Yes
- Supported Technologies DirectX 12
- Virtual Reality Ready Yes
- SLI Options 4-WAY
- Display Support:
- Multi Monitor
- Maximum Digital Resolution 5120x3200
- Maximum VGA Resolution 2048x1536
- HDCP Yes
- HDMI Yes
- Standard Display Connectors DVI-I, HDMI 2.0, 3 x DP 1.2
- Audio Input for HDMI Internal
- Power Specs:
- Maximum Graphics Card Power (W) 250W
- Minimum System Power Requirement (W) 600W
- Supplementary Power Connectors Two 8-pin
- Model:
- Product Code 98IRH5DHF7XH
- EAN Code 4895147119694
- Dimensions:
- Dimensions(with Bracket): 315*144.1*51 mm
- Dimensions(without Bracket): 298*129*51 mm
- PCI Express-compliant motherboard with one dual-width x 16 graphics slot
- 2 x 8-pin PCI Express supplementary power connectors
- Minimum 600W or greater system power supply
- 300MB of available hard-disk space
- 2GB system memory (4GB or higher recommended)
- Microsoft Windows 10, Windows 8 & 8.1, Windows 7, Windows Vista (32 or 64-bit)
- CD-ROM/DVD-ROM drive or Internet connection
- Windows XP no longer supported
