GALAX GeForce RTX™ 3070 EX (1-Click OC Feature)

8GB GDDR6 256-bit DP*3/HDMI/

For the EX series, we have an innovative fan design that creates a new trend in GPU cooling with the 102mm twin fans along with our proprietary Fan Blade - “Wings”. 11 fan blades being extraordinary, not only for the exquisite look but also providing high air flow and air pressure at minimum noise level. GALAX is bringing the new fans era to the world with its EX series.


Aside from the cooler, EX series also adopted non reference design PCB with enlarged area for more relaxed component layout and low heat density. Extra power phases also allow better power delivery and higher overclocking potential.


Product Code: 37NSL6MD2V7V


EAN: 4895147142944


Product Driver: Download


High-Res Photo: Download









1-Click OC allows you to boost your graphics cards with just one click! Download Xtreme Tuner now!
PC: Download
Android: Download
iOS: Download
  • 2nd Gen Ray Tracing Cores
  • 3rd Gen Tensor Cores
  • Microsoft® DirectX® Ultimate
  • GDDR6 Graphics Memory
  • NVIDIA DLSS
  • NVIDIA® GeForce Experience™
  • NVIDIA G-SYNC®
  • NVIDIA GPU Boost™
  • Game Ready Drivers
  • Vulkan RT API, OpenGL 4.6
  • DisplayPort 1.4a, HDMI 2.1
  • HDCP 2.3
  • VR Ready
  • All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.
GPU Engine Specs:
  • CUDA Cores 5888
  • Boost Clock (MHz) 1770
  • 1-Click OC Clock (MHz) 1785 (by installing Xtreme Tuner Plus Software and using 1-Click OC)
Memory Specs:
  • Memory Speed 14 Gbps
  • Standard Memory Config 8GB GDDR6
  • Memory Interface Width 256-bit
  • Memory Bandwidth (GB/sec) 448
Feature Support:
  • PCI-E 4.0
  • Windows 10 64-bit, Linux 64-bit
Fan Feature:
  • 2*102mm
  • Fan stop @ Idle (All Fan)
Display Support:
  • DisplayPort 1.4a x 3, HDMI 2.1
Dimensions:
  • Dimensions(with Bracket): 299*139*58mm
  • Dimensions(without Bracket): 285*124*58mm

Resizable BAR BIOS update for GeForce RTX 30 series: Download

  1. PCI Express-compliant motherboard with one dual-width x 16 graphics slot
  2. System Space for 3-slot card required
  3. 1 x PCIe 8-pin supplementary power connectors
  4. Minimum 650W or greater system power supply
  5. 32GB system memory recommended)
  6. Microsoft Windows 10 64-bit (Build 2004 or later recommended) or Linux 64-bit
