Customizable top HOF LED (control blinking frequency, brightness with GFE)
Polycarbonate cover with premium die-cast aluminum accents
Next generation IR3595 Digital PWM controller provides 2X switching frequency vs. previous generation
8 phase GPU + 2 phase memory power
IR3555 with next gen DrMOS and 60A output
Aerospace-grade GALAX Extreme Power Inductors provide ultra-long life, high endurance and low noise vs. normal power inductors
NVIDIA® GeForce® GTX® VR Ready
NVIDIA® Dynamic Super Resolution (DSR)
NVIDIA® Global Illumination (VXGI)
NVIDIA® GameWorks Technology
NVIDIA® GameStream Technology
NVIDIA® TXAA Technology
NVIDIA GPU Boost 2.0
NVIDIA PhysX® Technology
NVIDIA FXAA Technology
NVIDIA Adaptive Vertical Sync
NVIDIA Surround
Microsoft DirectX 12
NVIDIA® 3D Vision® Ready
NVIDIA SLI® Ready Technology
NVIDIA CUDA® technology
PCI Express 3.0 support
OpenGL 4.4 support
OpenCL support
NVIDIA SHIELD Ready
NVIDIA G-Sync Ready
All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.
GPU Engine Specs:
CUDA Cores 2816
Base Clock (MHz) 1101
Boost Clock (MHz) 1190
Memory Specs:
Memory Speed 3505 (7010 ) MHz
Standard Memory Config 6144MB
Memory Interface Width 384-bit GDDR5
Memory Bandwidth (GB/sec) 336.5
Feature Support:
OpenGL 4.4
Bus Support PCI-E 3.0
Certified for Windows 8 Yes
Supported Technologies DirectX 12
Virtual Reality Ready Yes
SLI Options 4-WAY
Display Support:
Multi Monitor
Maximum Digital Resolution 5120x3200
Maximum VGA Resolution 2048x1536
HDCP Yes
HDMI Yes
Standard Display Connectors DVI-I, HDMI 2.0, 3 x DP 1.2
Audio Input for HDMI Internal
Power Specs:
Maximum Graphics Card Power (W) 250W
Minimum System Power Requirement (W) 600W
Supplementary Power Connectors Two 8-pin
Model:
Product Code 98IRH5DHF7HD
EAN Code 4895147119694
Dimensions:
Dimensions(with Bracket): 315*144.1*51 mm
Dimensions(without Bracket): 298*129*51 mm
PCI Express-compliant motherboard with one dual-width x 16 graphics slot
2 x 8-pin PCI Express supplementary power connectors
Minimum 600W or greater system power supply
300MB of available hard-disk space
2GB system memory (4GB or higher recommended)
Microsoft Windows 10, Windows 8 & 8.1, Windows 7, Windows Vista (32 or 64-bit)
