GALAX GeForce RTX™ 3090 Ti HOF

GALAX GeForce RTX™ 3090 Ti HOF

GALAX GeForce RTX™ 3090 Ti HOF

24GB GDDR6X 384-bit DP*3/HDMI/

Featuring a record-breaking 10,752 CUDA cores, aggressive 24+4 phase digital power design and the all-new dual PCI-E 5.0 12VHPWR power connector which supports up to 516W input power at Performance Mode, GeForce RTX™ 3090 Ti Hall Of Fame challenges the overclocking enthusiasts to go beyond their limits as it is the most powerful GPU among the HOF 30 series. As the GPU supports both Performance and Silent Mode with its signature dual BIOS feature, users can achieve boost clock of 1,920MHz (Performance Mode) or 1,860MHz (Silent Mode) respectively.


Product Code: 39IXM5MD5ZEH


EAN: 4895147149318


Product Driver: Download


High-Res Photo: Download

































1-Click OC allows you to boost your graphics cards with just one click! Download Xtreme Tuner now!

PC: Download Android: Download iOS: Download
Customize your RGB color with Xtreme Tuner, or synchronize with the rest of your system, by connecting the graphics card to +12V RGB header of your motherboard or other RGB control system, using the included cable.Quick User Guide
HOF Panel III shows the next generation of HOF information on a 4.3” full color TFT LCD panel, supporting real time animated graphics card information display.
Coup de Coeur Award from Overclocking.com (France)
4.5/5 Stars Rating by IT Hardware (Poland)
Design Award by IT Hardware (Poland)
Quality Award by IT Hardware (Poland)
  • 2nd Gen Ray Tracing Cores
  • 3rd Gen Tensor Cores
  • Microsoft® DirectX® Ultimate
  • GDDR6X Graphics Memory
  • NVIDIA DLSS
  • NVIDIA® GeForce Experience™
  • NVIDIA G-SYNC®
  • NVIDIA GPU Boost™
  • Game Ready Drivers
  • Vulkan RT API, OpenGL 4.6
  • DisplayPort 1.4a, HDMI 2.1
  • HDCP 2.3
  • VR Ready
  • NVIDIA® NVLink® (SLI Ready)
  • All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.
GPU Engine Specs:
  • CUDA Cores 10752
  • Boost Clock (MHz) 1920
  • 1-Click OC Clock (MHz) 1935 (by installing Xtreme Tuner Plus Software and using 1-Click OC)
Memory Specs:
  • Memory Speed 21 Gbps
  • Standard Memory Config 24GB
  • Memory Interface Width 384-bit GDDR6X
  • Memory Bandwidth (GB/sec) 1008
Feature Support:
  • PCI-E 4.0
  • Windows 10 64-bit, Linux 64-bit
Fan Feature:
  • 1*92mm, 2*102mm
  • Fan stop @ Idle (All Fan)
Display Support:
  • DisplayPort 1.4a x 3, HDMI 2.1
Dimensions:
  • Dimensions(with Bracket): 352*160*68mm
  • Dimensions(without Bracket): 339*144*68mm
  1. PCI Express-compliant motherboard with one dual-width x 16 graphics slot
  2. System Space for 3-slot card required
  3. 6 x PCIe 8-pin supplementary power connectors (with 2*Triple 8-pin PCI-E adapter in box) / 2 x PCIe 5.0 12-pin supplementary power connectors
  4. Minimum 1000W or greater system power supply
  5. 32GB system memory recommended)
  6. Microsoft Windows 10 64-bit (Build 2004 or later recommended) or Linux 64-bit
