GPU Engine Specs:
Base Clock (MHz) 1366
Boost Clock (MHz) 1468
Memory Specs:
Memory Speed 3504 (7008) Mhz
Standard Memory Config 2048MB
Memory Interface Width 128-bit DDR5
Memory Bandwidth (GB/sec) 112
Feature Support:
OpenGL 4.5
Bus Support PCI-E 3.0
Certified for Windows 8 Yes
Supported Technologies DirectX 12
Display Support:
Multi Monitor 3 Displays
Maximum Digital Resolution 4096x2160@60Hz
HDCP Yes
HDMI Yes
Standard Display Connectors DP 1.4, HDMI 2.0b, Dual Link-DVI
Standard Graphics Card Dimensions:
Dimensions(with Bracket) 182*121*39mm
Dimensions(without Bracket) 166*69*34mm
Power Specs:
Maximum Graphics Card Power (W) 75W
Minimum System Power Requirement (W) 300W
Model:
Product Code 50NPH8DSP2MN
UPC Code 4895147125756
PCI Express-compliant motherboard with one dual-width x 16 graphics slot
Minimum 300W or greater system power supply
350MB of available hard-disk space
2GB system memory (4GB or higher recommended)
Microsoft Windows 10, Windows 8 & 8.1, Windows 7(32 or 64-bit)
